Industrial Gear Unit

Industrial Gear Unit

Product Details:

  • Gear Type Bevel Gears
  • Material Iron
  • Gear Tooth Profile Helical Gear
  • Gearing Arrangement Planetary
  • Efficiency >95%
  • Click to view more
X

Price And Quantity

Product Specifications

  • Iron
  • Planetary
  • Bevel Gears
  • >95%
  • Helical Gear

Trade Information

  • Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Paypal
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • All India

Product Description

Well-equipped with technically advanced facilities and equipments we are engaged in manufacturing and exporting a qualitative range Industrial Gear Unit. These units are manufactured as per the set industrial norms and standards using the optimum quality materials. The materials we use are procured from the most reputed and trusted vendors of the market. Our Industrial Gear Unit is applicable where extremely large torque ratings are required. We offer these units at the market leading price to the clients.

Features of Industrial Gear Unit:
  •     Less maintenance
  •     Rust free finish
  •     Rigged design
Industrial Gear Unit Specifications:
  •     Sizes 4
  •     Torque range 90.000 - 200.000 NM
  •     Performance 2,2 kW - 1.000 kW
  •     Efficiency >95%

NO RD industrial gear units have been developed according to the tried-and-tested uni case housing principle. The uni case is a one-piece housing, into which all the bearings are integrated. The finishing of this uni case is carried out with in unique jig, on state-of -the-art CNC machines. The uni case concept features highest levels of precision, rigidity and strength. There are no dividing seams between the drive and the gear unit housing which are subjected to transverse forces or torque. The uni case principle allows the shaft axes to be staggered, resulting in a more compact design which allows the use of larger roller bearings to guarantee a long operating life.

Industrial Gear Machine Advantages:
  •     Optimum sealing
  •     Quiet running
  •     High torque capacity
  •     Increased lubricant life
  •     Maximized operating life of bearings and gears
  •     High reliability
  •     Long operating life
  •     Symmetrical design
  •     B14 face as standard on output side
  •     6 installation configurations
  •     Mirror-image installation possible
  •     Same housing size, installation dimensions for all ratios (2 and 3 stage)

Technical Specification

Sizes:

7

Mounting position:

M1/M3

Ratio:

6,3 - 22,4:1


  • Performance: 50 - 1.500 kW
  • Torque range: 15.000 - 75.000 Nm
